DT SwissE 1900 SPLINE
€479 MSRP per wheelset, "from" price (lowest configuration), DT Swiss EU site
- Wheel size
- 29" / 27.5"
- Inner width
- 30 mm
- Hub
- 370, Ratchet LN 18
- Rim
- Aluminum, Hooked / Crotchet tubeless TC
- Max. system weight
- 130 kg
- E-bike approved
- Yes (max. 32Km/h or max. 250W)
- Weight
- 1,994 gPer set (front + rear), lightest configuration, claimed
Overview
E 1900 SPLINE is an aluminum Enduro wheelset from DT Swiss with 370 hubs (Ratchet LN 18) and 30 mm inner width, in 29" / 27.5"; from 1994 g per set. MSRP from €479 per set.
The best enduro wheelset for your debut, providing the confidence needed to start an adventure and enjoy those special freewheeling moments.
The E 1900 SPLINE is part of DT Swiss's Enduro wheel range; DT Swiss approves it for e-bike use (pedelecs up to 32 km/h / 250 W). It is offered in 29" and 27.5" with 30 mm inner width, with IS (6-bolt), Center Lock brake interfaces and Shimano Micro Spline, Shimano MTB, SRAM XD freehub options.
- 370 hub with Ratchet LN 18 freehub
- Aluminum rim, Hooked / Crotchet tubeless TC, 30 mm inner width
- Spokes: DT champion® Straightpull
- Approved for e-bikes, max. system weight 130 kg
Gallery
Full specifications
General
- Weight front wheel
- 940–1005 g
- Weight rear wheel
- 1054–1140 g
- Weight per set
- from 1994 g
- Max. system weight
- 130 kg
- ASTM classification
- 4
- Approved for e-bikes
- Yes (max. 32Km/h or max. 250W)
Rim
- Material
- Aluminum
- Rim joint
- Sleeve joint
- Tire interface
- Hooked / Crotchet tubeless TC
- Valve hole
- Presta
- Rim diameter
- 29" / 700C; 27.5" / 650B
- Rim height
- 20 mm
- Inner width
- 30 mm
- Outer width
- 35 mm
Hub
- Hub type
- 370
- Axle system (front)
- 15 mm Thru Axle
- Axle system (rear)
- 12 mm Thru Axle
- Built-in dimension (front)
- 110 mm Boost; 100 mm
- Built-in dimension (rear)
- 148 mm Boost; 142 mm
- Brake interface
- Disc IS (6-bolt); Disc Center Lock
- Cassette interface
- Shimano Micro Spline; Shimano MTB; Sram XD
- Freehub body
- Shim. 12SP Light (ASL12); Shimano Forged (ASF); SRAM XD MTB (ASRAM)
- Freehub system
- Ratchet LN 18
Spokes & Nipples
- Spokes left
- DT champion® Straightpull
- Spokes right
- DT champion® Straightpull
- Spoke pattern
- Three-cross (1:1)
- Nipples
- DT ProLock Squorx ProHead alu
Inclusive
- Inclusive
- Tubeless tape 32 mm Tubeless valve MTB 32 mm
Manufacturer specification — DT Swiss. Specs and prices can change; check with the brand or your dealer.
DT Swiss Enduro versions compared
| E 1900 SPLINE | EX 1700 CLASSIC | EXC 1500 CLASSIC | EXC 1200 CLASSIC | |
|---|---|---|---|---|
| Price | €479 | €749 | €1,699 | €2,499 |
| Wheel size | 29" / 27.5" | 29" / 27.5" | 29" / 27.5" | 29" / 27.5" |
| Inner width | 30 mm | 30 mm | 30 mm | 30 mm |
| Hub | 370, Ratchet LN 18 | 350, Ratchet DEG 72 | 240, Ratchet DEG 90 | 180, Ratchet DEG 90 |
| Rim | Aluminum, Hooked / Crotchet tubeless TC | Aluminum, Hooked / Crotchet tubeless TC | Carbon, Hookless tubeless TSS | Carbon, Hookless tubeless TSS |
| Max. system weight | 130 kg | 130 kg | 130 kg | 130 kg |
| E-bike approved | Yes (max. 32Km/h or max. 250W) | Yes (max. 32Km/h or max. 250W) | Yes (max. 32Km/h or max. 250W) | Yes (max. 32Km/h or max. 250W) |
| Weight | 1,994 g | 1,916 g | 1,683 g | 1,644 g |
eMTBs that come with the DT Swiss Enduro
DT Swiss E 1900 SPLINE: FAQ
How much does the DT Swiss E 1900 SPLINE cost?
€479 (MSRP per wheelset, "from" price (lowest configuration), DT Swiss EU site). Prices vary by country and retailer.
How much does the DT Swiss E 1900 SPLINE weigh?
DT Swiss quotes 1,994 g (Per set (front + rear), lightest configuration, claimed).
Is the DT Swiss E 1900 SPLINE suitable for e-bikes?
Yes — DT Swiss lists it as e-bike rated or e-bike specific.
What are the key specs of the DT Swiss E 1900 SPLINE?
Wheel size: 29" / 27.5"; Inner width: 30 mm; Hub: 370, Ratchet LN 18; Rim: Aluminum, Hooked / Crotchet tubeless TC; Max. system weight: 130 kg; E-bike approved: Yes (max. 32Km/h or max. 250W).
What other versions of the DT Swiss Enduro are there?
EX 1700 CLASSIC (€749), EXC 1500 CLASSIC (€1,699), EXC 1200 CLASSIC (€2,499).
