DT SwissHX 1700 SPLINE
€759 MSRP per wheelset, "from" price (lowest configuration), DT Swiss EU site
- Wheel size
- 29" / 27.5"
- Inner width
- 30 mm
- Hub
- 350, Ratchet DEG 60
- Rim
- Aluminum, Hooked / Crotchet tubeless TC
- Max. system weight
- 150 kg
- E-bike approved
- Yes (max. 32Km/h or max. 250W)
- Weight
- 2,019 gPer set (front + rear), lightest configuration, claimed
Overview
HX 1700 SPLINE is an aluminum Hybrid MTB wheelset from DT Swiss with 350 hubs (Ratchet DEG 60) and 30 mm inner width, in 29" / 27.5"; from 2019 g per set. MSRP from €759 per set.
An aluminum e-bike wheel designed to better resist brake and drive torque, ready for the extended use of e-mountainbiking.
The HX 1700 SPLINE is part of DT Swiss's Hybrid MTB range, which is built specifically for e-MTBs: reinforced hybrid spokes, hardened freehub interfaces and rims chosen for higher system weight and motor torque. It is offered in 29" and 27.5" with 30 mm inner width, with Center Lock brake interfaces and SRAM XD, Shimano Micro Spline freehub options.
- 350 hub with Ratchet DEG 60 freehub
- Aluminum rim, Hooked / Crotchet tubeless TC, 30 mm inner width
- Spokes: DT hybrid 2 Straightpull
- DF anti-pedal-kickback system (DF HYB 0°/10°)
- Approved for e-bikes, max. system weight 150 kg
Gallery
Full specifications
General
- Weight front wheel
- 898–951 g
- Weight rear wheel
- 1121–1193 g
- Weight per set
- from 2019 g
- Max. system weight
- 150 kg
- ASTM classification
- 4
- Approved for e-bikes
- Yes (max. 32Km/h or max. 250W)
Rim
- Material
- Aluminum
- Rim joint
- Welded
- Tire interface
- Hooked / Crotchet tubeless TC
- Valve hole
- Presta
- Rim diameter
- 29" / 700C; 27.5" / 650B
- Rim Height (front)
- 21 mm
- Rim Height (rear)
- 22 mm
- Inner width
- 30 mm
- Outer width (front)
- 34.7 mm
- Outer width (rear)
- 35 mm
Hub
- Hub type
- 350
- Axle system (front)
- 15 mm Thru Axle
- Axle system (rear)
- 12 mm Thru Axle
- Built-in dimension (front)
- 110 mm Boost
- Built-in dimension (rear)
- 148 mm Boost
- Brake interface
- Disc Center Lock
- Cassette interface
- Sram XD; Shimano Micro Spline
- Freehub body
- SRAM XD Steel (SSRAM); Shimano 12SP Steel (SS12)
- Freehub system
- Ratchet DEG 60
- Anti-Pedal Kickback System
- DF HYB 0°/10°
Spokes & Nipples
- Spokes left
- DT hybrid 2 Straightpull
- Spokes right
- DT hybrid 2 Straightpull
- Spoke pattern
- Three-cross (1:1)
- Nipples
- DT ProLock Squorx ProHead alu
Inclusive
- Inclusive
- Tubeless tape 32 mm TL valve Asy Alu black18-25 mm IS 6-bolt adapter MTB
Manufacturer specification — DT Swiss. Specs and prices can change; check with the brand or your dealer.
DT Swiss Hybrid MTB versions compared
| H 1900 SPLINE | HX 1700 SPLINE | HXC 1500 SPLINE | HXC 1200 SPLINE | |
|---|---|---|---|---|
| Price | €499 | €759 | €1,729 | €2,499 |
| Wheel size | 29" / 27.5" | 29" / 27.5" | 29" / 27.5" | 29" / 27.5" |
| Inner width | 30 mm / 35 mm | 30 mm | 30 mm | 30 mm |
| Hub | 370, Ratchet LN 18 | 350, Ratchet DEG 60 | 240, Ratchet DEG 60 | 180, Ratchet EXP OS 42 |
| Rim | Aluminum, Hooked / Crotchet tubeless TC | Aluminum, Hooked / Crotchet tubeless TC | Carbon, Hookless tubeless TSS | Carbon, Hookless tubeless TSS |
| Max. system weight | 150 kg | 150 kg | 140 kg | 140 kg |
| E-bike approved | Yes (max. 32Km/h or max. 250W) | Yes (max. 32Km/h or max. 250W) | Yes (max. 32Km/h or max. 250W) | Yes (max. 32Km/h or max. 250W) |
| Weight | 2,066 g | 2,019 g | 1,835 g | 1,809 g |
DT Swiss HX 1700 SPLINE: FAQ
How much does the DT Swiss HX 1700 SPLINE cost?
€759 (MSRP per wheelset, "from" price (lowest configuration), DT Swiss EU site). Prices vary by country and retailer.
How much does the DT Swiss HX 1700 SPLINE weigh?
DT Swiss quotes 2,019 g (Per set (front + rear), lightest configuration, claimed).
Is the DT Swiss HX 1700 SPLINE suitable for e-bikes?
Yes — DT Swiss lists it as e-bike rated or e-bike specific.
What are the key specs of the DT Swiss HX 1700 SPLINE?
Wheel size: 29" / 27.5"; Inner width: 30 mm; Hub: 350, Ratchet DEG 60; Rim: Aluminum, Hooked / Crotchet tubeless TC; Max. system weight: 150 kg; E-bike approved: Yes (max. 32Km/h or max. 250W).
What other versions of the DT Swiss Hybrid MTB are there?
H 1900 SPLINE (€499), HXC 1500 SPLINE (€1,729), HXC 1200 SPLINE (€2,499).
