TrickstuffDächle Disc HD
€34 MSRP per disc, from; Germany, EUR
- Rotor sizes
- 160 / 180 / 203 mm
- Thickness
- 2.05 mm
- Friction ring width
- 15.5 mm
- Mount
- 6-bolt (IS)
- Weight
- 120–195 g
- Weight
- 150 g180 mm, claimed (160 mm: 120 g, 203 mm: 195 g)
Overview
Trickstuff Dächle Disc HD: 2.05 mm heavy-duty 6-bolt rotor in 160, 180 and 203 mm (120–195 g), from €34 (MSRP).
The Dächle Disc HD is Trickstuff's heavy-duty brake rotor, built for long, hard descents. A massive 15.5 mm friction ring and 2.05 mm thickness give it a large heat capacity and high fade resistance, while vacuum-hardened stainless steel absorbs braking energy and releases it to the air.
Its hole pattern provides consistent pad cleaning and prevents pad glazing. It uses the 6-bolt IS interface and comes in 160, 180 and 203 mm diameters.
- 2.05 mm thick, 15.5 mm wide friction ring for high heat capacity
- Vacuum-hardened stainless steel
- Hole pattern cleans pads and prevents glazing
- 160 / 180 / 203 mm, 6-bolt
Gallery
Full specifications
General
- Brake interface
- Disc IS (6-bolt)
- Material
- Stainless steel, hardened
Brake Disc
- Disc diameter
- 160, 180, 203 mm
- Brake disc thickness
- 2.05 mm
- Friction ring width
- 15.5 mm
- Weight 160 mm
- 120 g
- Weight 180 mm
- 150 g
- Weight 203 mm
- 195 g
Manufacturer specification — Trickstuff. Specs and prices can change; check with the brand or your dealer.
Trickstuff Dächle Disc versions compared
| Dächle Disc HD | Dächle Disc UL | |
|---|---|---|
| Price | €34 | €34 |
| Rotor sizes | 160 / 180 / 203 mm | 140 / 160 / 180 / 203 mm |
| Thickness | 2.05 mm | 1.85 mm (140/160), 2.05 mm (180/203) |
| Friction ring width | 15.5 mm | 13.75 / 14.25 mm |
| Mount | 6-bolt (IS) | 6-bolt (IS) |
| Weight | 120–195 g | 70–152 g |
| Weight | 150 g | 119 g |
| E-bike rated | — | — |
Trickstuff Dächle Disc HD: FAQ
How much does the Trickstuff Dächle Disc HD cost?
€34 (MSRP per disc, from; Germany, EUR). Prices vary by country and retailer.
How much does the Trickstuff Dächle Disc HD weigh?
Trickstuff quotes 150 g (180 mm, claimed (160 mm: 120 g, 203 mm: 195 g)).
Is the Trickstuff Dächle Disc HD suitable for e-bikes?
Trickstuff does not specifically rate it for e-bikes. Check the manufacturer’s approval and your bike maker’s recommendations before fitting it to an eMTB.
What are the key specs of the Trickstuff Dächle Disc HD?
Rotor sizes: 160 / 180 / 203 mm; Thickness: 2.05 mm; Friction ring width: 15.5 mm; Mount: 6-bolt (IS); Weight: 120–195 g.
What other versions of the Trickstuff Dächle Disc are there?
Dächle Disc UL (€34).
