ScottVoltage eRIDE
- Price
- £5,999 – £9,599
- Motor
- TQ HPR6060 Nm
- Battery
- 360 Wh+160 Wh range extender
- Travel F / R
- 150 / 155 mm
- Wheels
- 29"
- Weight
- 19.1 kg – 19.9 kg
Overview
The Voltage eRIDE is Scott's lightweight long-travel trail e-MTB: a carbon frame with 155 mm of rear travel, a 150–160 mm fork and TQ's compact HPR60 motor (60 Nm).
Each build ships with a 360 Wh internal battery plus a 160 Wh range extender; claimed weights start at 19.1 kg without the extender.
- TQ HPR60, 60 Nm
- 360 Wh + 160 Wh range extender
- 155 mm rear travel
- From 19.1 kg claimed
Scott Voltage eRIDE builds
Voltage eRIDE builds compared
| Voltage eRIDE 920 | Voltage eRIDE 910 | Voltage eRIDE 900 Tuned | |
|---|---|---|---|
| Price | £5,999 | £7,799 | £9,599 |
| Frame | Carbon main frame, alloy rear | Carbon | Carbon |
| Fork | Marzocchi Z2 Air Rail, Sweep Adj | FOX 36 Rhythm Air Grip, Sweep Adj. | FOX 36 Factory Air GripX2, HSC - LSC - HSR - LSR adjustable |
| Shock | X-Fusion NUDE 5 RLX Trunnion; SCOTT custom w | FOX FLOAT X NUDE EVOL Piggy Back Trunnion | FOX FLOAT X NUDE Factory EVOL Piggy Back Trunnion |
| Derailleur | SRAM Eagle 70 Transmission 12 Speed | SRAM S1000 Eagle AXS Transmission 12 Speed; Wireless Electronic Shift System | SRAM GX Eagle AXS Transmission 12 Speed; Wireless Electronic Shift System |
| Brakes | SRAM DB4 Stealth 4-Piston Disc | SRAM Maven Bronze Stealth 4-Piston Disc | SRAM Maven Silver Stealth 4-Piston Disc |
| Wheels | Syncros X-30S, 32H | Syncros X-30S, 32H | — |
| Display | TQ HPR; Bluetooth | TQ HPR; Bluetooth | TQ HPR Color; Bluetooth |
| Weight | 19.8 kg | 19.9 kg | 19.1 kg |
Voltage eRIDE geometry
| Size | S | M | L | XL |
|---|---|---|---|---|
| AHead tube angle | 63.9° | 63.9° | 63.9° | 63.9° |
| BHead tube length | 110 mm | 110 mm | 120 mm | 130 mm |
| CTop tube horizontal | 580.2 mm | 600 mm | 629.9 mm | 659.8 mm |
| DStandover height | 765 mm | 765 mm | 772 mm | 788 mm |
| EBB offset | 27.4 mm | 27.5 mm | 27.4 mm | 27.3 mm |
| FBB height | 349.6 mm | 349.5 mm | 349.6 mm | 349.7 mm |
| GWheel base | 1232.8 mm | 1252.6 mm | 1284.8 mm | 1316.9 mm |
| IBB center to top of seattube | 404.6 mm | 424.5 mm | 449.6 mm | 479.7 mm |
| JSeat angle | 77.1° | 77.1° | 77.1° | 77.1° |
| KChainstay | 455 mm | 455 mm | 455 mm | 455 mm |
| LReach | 437.4 mm | 457.2 mm | 485 mm | 512.7 mm |
| MStack | 622.3 mm | 622.4 mm | 631.3 mm | 640.2 mm |
| NStem length | 40 mm | 40 mm | 50 mm | 50 mm |
| OTrail | 135.7 mm | 135.7 mm | 135.7 mm | 135.7 mm |
| PFork length | 571 mm | 571 mm | 571 mm | 571 mm |
| QMaximum Seatpost Insertion | 190 mm | 210 mm | 235 mm | 265 mm |
| RCrank Length | 170 mm | 170 mm | 175 mm | 175 mm |
Source: Scott.
Scott Voltage eRIDE: FAQ
How much does the Scott Voltage eRIDE cost?
£5,999 – £9,599 depending on the build (Voltage eRIDE 920 £5,999, Voltage eRIDE 910 £7,799, Voltage eRIDE 900 Tuned £9,599); UK RRP, VAT incl..
How many Scott Voltage eRIDE builds are there?
3: Voltage eRIDE 920, Voltage eRIDE 910, Voltage eRIDE 900 Tuned. They share the frame platform and differ mainly in suspension, drivetrain, wheels and weight.
How much does the Scott Voltage eRIDE weigh?
Claimed weights range from 19.1 kg (Voltage eRIDE 900 Tuned) to 19.9 kg (Voltage eRIDE 910).
What motor and battery does the Scott Voltage eRIDE use?
TQ HPR60 (60 Nm) with a 360 Wh battery (+160 wh range extender).
How much travel does the Scott Voltage eRIDE have?
150 mm fork and 155 mm rear travel on 29" wheels.
