ScottLumen eRIDE
- Price
- £5,999 – £8,999
- Motor
- TQ HPR6060 Nm
- Battery
- 360 Wh+160 Wh range extender
- Travel F / R
- 140 / 130 mm
- Wheels
- 29"
- Weight
- 17.8 kg – 18.5 kg
Overview
The Lumen eRIDE is Scott's down-country e-MTB, built on the Spark platform with an integrated shock: 130 mm of rear travel, a 140 mm fork and the TQ HPR60 motor (60 Nm) with a 360 Wh internal battery and a 160 Wh range extender.
Claimed weights run from 17.8 to 18.5 kg, close to a regular trail bike.
- TQ HPR60, 60 Nm
- 360 Wh + 160 Wh range extender
- 130 mm rear / 140 mm fork
- From 17.8 kg claimed
Scott Lumen eRIDE builds
Lumen eRIDE builds compared
| Lumen eRIDE 920 | Lumen eRIDE 910 | Lumen eRIDE 900 | |
|---|---|---|---|
| Price | £5,999 | £7,599 | £8,999 |
| Frame | Carbon | Carbon | Carbon |
| Fork | RockShox Recon Gold RL Solo Air, 15x110mm axle | Fox 34 Rhythm Grip, 3P | Fox 36SL Performance Elite Grip SL , 3P with low speed adj. |
| Shock | X-Fusion Nude 5 RLX Trunnion | Fox Nude 6 EVOL Trunnion | Fox Nude 6 EVOL Trunnion |
| Derailleur | SRAM Eagle 70 Transmission | SRAM S1000 Eagle AXS Transmission 12 Speed | SRAM GX Eagle AXS Transmission 12 Speed |
| Brakes | SRAM DB4 4-Piston | SRAM Motive Bronze 4-Piston | SRAM Motive Silver 4-Piston |
| Wheels | Alex Rims X-30S 32H, Sleeve Joint | Alex Rims X-30S 32H, Sleeve Joint | — |
| Display | TQ HPR | TQ HPR | TQ HPR |
| Weight | 18.5 kg | 17.8 kg | 18.2 kg |
Lumen eRIDE geometry
| Size | S | M | L | XL |
|---|---|---|---|---|
| AHead tube angle | 65.5° | 65.5° | 65.5° | 65.5° |
| BHead tube length | 110 mm | 110 mm | 120 mm | 135 mm |
| CTop tube horizontal | 562 mm | 589 mm | 620 mm | 645 mm |
| DStandover height | 765 mm | 767 mm | 780 mm | 800 mm |
| EBB offset | -38.5 mm | -38.5 mm | -38.5 mm | -38.5 mm |
| FBB height | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm |
| GWheel base | 1176 mm | 1206 mm | 1240 mm | 1270 mm |
| IBB center to top of seattube | 415 mm | 440 mm | 480 mm | 520 mm |
| JSeat angle | 76.8° | 77° | 77.2° | 77.5° |
| KChainstay | 450 mm | 450 mm | 450 mm | 450 mm |
| LReach | 416 mm | 446 mm | 476 mm | 501 mm |
| MStack | 615 mm | 615 mm | 625 mm | 638 mm |
| NStem Length | 50 mm | 60 mm | 70 mm | 70 mm |
| PFork length | 540 mm | 540 mm | 540 mm | 540 mm |
| QMaximum Seatpost Insertion | 150 mm | 175 mm | 215 mm | 255 mm |
| RHandlebar Width | 760 mm | 760 mm | 760 mm | 760 mm |
Source: Scott.
Scott Lumen eRIDE: FAQ
How much does the Scott Lumen eRIDE cost?
£5,999 – £8,999 depending on the build (Lumen eRIDE 920 £5,999, Lumen eRIDE 910 £7,599, Lumen eRIDE 900 £8,999); UK RRP, VAT incl..
How many Scott Lumen eRIDE builds are there?
3: Lumen eRIDE 920, Lumen eRIDE 910, Lumen eRIDE 900. They share the frame platform and differ mainly in suspension, drivetrain, wheels and weight.
How much does the Scott Lumen eRIDE weigh?
Claimed weights range from 17.8 kg (Lumen eRIDE 910) to 18.5 kg (Lumen eRIDE 920).
What motor and battery does the Scott Lumen eRIDE use?
TQ HPR60 (60 Nm) with a 360 Wh battery (+160 wh range extender).
How much travel does the Scott Lumen eRIDE have?
140 mm fork and 130 mm rear travel on 29" wheels.
