MondrakerZendit S
- Motor
- DJI Avinox M2S150 Nm; 1300 W peak
- Battery
- 800 WhIntegrated, non-removable
- Travel F / R
- 170 / 165 mm
- Wheels
- Mullet 29" / 27.5"
- Frame
- Carbon front, alloy rear
Overview
The Zendit S is the €6,499 entry point: carbon front triangle with an alloy rear end, a RockShox ZEB Base fork and Super Deluxe Select shock, mechanical SRAM Eagle 70 Transmission, Maven Base brakes and Mavic E-Access XR30 wheels, with the same Avinox M2S motor and 800 Wh battery as the top models.
Zendit is Mondraker's flagship full-power enduro eMTB, built around the DJI Avinox M2S motor (up to 150 Nm and 1,300 W) and an integrated 800 Wh battery. It runs a mullet wheel setup with a 170 mm fork and 165 mm of rear travel from the ZERO suspension system, flip-chip adjustable geometry with a 63.5° head angle and five sizes from S to XL.
The XR, RR S and RR use a full Stealth Air carbon frame that can also be set up with a 29" rear wheel. The R and S, added in October 2026, pair the same carbon front triangle with an alloy swingarm and rocker link and are mullet-only.
- DJI Avinox M2S: up to 150 Nm and 1,300 W
- Integrated 800 Wh battery
- 170 mm fork, 165 mm rear travel, mullet wheels
- Flip-chip geometry, 63.5° head angle
Gallery
Full specifications
Frame & suspension
- Frame
- Zendit Stealth Air Carbon front triangle, Stealth Alloy rear triangle, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
- Sizes
- S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
- Rear shock
- RockShox Super Deluxe Select, 205x65mm, Trunnion top mount, 30x8mm bottom bushings
- Shock settings
- C34 compression, R55 rebound, 4 tokens, X25 lockout force
- Fork
- RockShox ZEB Base 29, Delta RC, 170mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: low-speed compression, Extl rebound, air preload
E-system
- Display
- Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)
- Motor
- Avinox M2S
- Battery
- Avinox 800Wh Battery / Avinox 4A Charger
Drivetrain
- Crankset
- E.13 Helix Core E*Spec Plus, All sizes: 155mm
- Chainring
- Sram Eagle 36T T-Type, 104BCD, steel, CL55
- Chain
- Sram 70 T-Type, 12s Flattop, PowerLock
- Rear derailleur
- Sram 70 Eagle, T-Type, 12s
- Shift levers
- Sram Trigger 70, 12s, T-Type Actuation
- Cassette
- Sram XS-1270, 10-52T, 12s
Brakes
Zendit geometry
| Size | S | M | M/L | L | XL |
|---|---|---|---|---|---|
| ASeat tube length | 380 mm | 410 mm | 435 mm | 460 mm | 490 mm |
| BTop tube length | 586 mm | 606 mm | 628 mm | 650 mm | 672 mm |
| CBottom bracket drop | 6 mm / 11 mm | 6 mm / 11 mm | 6 mm / 11 mm | 6 mm / 11 mm | 6 mm / 11 mm |
| DBottom bracket height | 345 mm / 340 mm | 345 mm / 340 mm | 345 mm / 340 mm | 345 mm / 340 mm | 345 mm / 340 mm |
| EChainstay length | 450 mm / 451 mm | 450 mm / 451 mm | 450 mm / 456 mm | 455 mm / 456 mm | 455 mm / 456 mm |
| FSeat tube angle | 73.5° / 73.15° | 73.5° / 73.15° | 73.5° / 73.15° | 73.5° / 73.15° | 73.5° / 73.15° |
| GEffective seat tube angle | 77° / 76.65° | 77° / 76.65° | 77° / 76.65° | 77° / 76.65° | 77° / 76.65° |
| HHead tube angle | 63.5° / 63.15° | 63.5° / 63.15° | 63.5° / 63.15° | 63.5° / 63.15° | 63.5° / 63.15° |
| IFork Offset | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| JWheelbase | 1241 mm / 1242 mm | 1261 mm / 1262 mm | 1286 mm / 1287 mm | 1315 mm / 1316 mm | 1339 mm / 1340 mm |
| KHead tube length | 110 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| LReach | 440 mm / 436 mm |
Zendit: builds compared
Zendit range →| Zendit S | Zendit R | Zendit RR | Zendit RR S | Zendit XR | |
|---|---|---|---|---|---|
| Price | €6,499 | €7,499 | €8,499 | €10,499 | €12,499 |
| Frame | Carbon front, alloy rear | Carbon front, alloy rear | Stealth Air carbon | Stealth Air carbon | Stealth Air carbon |
| Fork | RockShox ZEB Base 29, Delta RC | Fox 38 29 Float GRIP Performance, 170mm | Fox 38 29 Float GRIP X2 Factory Kashima, 170mm | Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm | Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm |
| Shock | RockShox Super Deluxe Select | Fox Float-X LV Performance | Fox Float X Factory Kashima Evol LV 205x65mm | Fox Float X Factory Kashima Evol LV 205x65mm | Fox Float X2 Factory Kashima 205x65mm |
| Derailleur | Sram 70 Eagle | Sram S1000 Eagle AXS | Sram S1000 Eagle AXS | Sram X0 Eagle AXS T-Type | Sram X0 Eagle AXS T-Type |
| Brakes | Sram Maven Base | Sram Maven Base | Sram Maven Base | Sram Maven Silver | Sram Maven Ultimate |
| Wheels | Mavic E-Access XR30, aluminium | DT Swiss Hybrid H 1900 SPLINE, aluminum | DT Swiss Hybrid H 1900 SPLINE, aluminum | DT Swiss Hybrid HX 1700 Spline, 30mm internal width | DT Swiss Hybrid HXC 1500 Spline, Carbon |
| Display | Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R) | Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R) |
Zendit S: FAQ
How much does the Mondraker Zendit S cost?
€6,499 (RRP Germany, VAT incl.). The Zendit range runs from €6,499 (Zendit S) to €12,499 (Zendit XR). Prices vary by country and dealer.
What motor and battery does the Mondraker Zendit S have?
DJI Avinox M2S (150 Nm; 1300 W peak). 800 Wh battery — integrated, non-removable.
How much suspension travel does the Mondraker Zendit S have?
170 mm at the fork and 165 mm at the rear, on mullet 29" / 27.5" wheels.
What sizes does the Mondraker Zendit S come in?
S, M, M/L, L, XL. Check the geometry table to compare reach and stack between sizes.
What is the difference between the Zendit S and the Zendit R?
They share the Zendit frame platform and motor; the differences are in the parts — fork: RockShox ZEB Base 29 vs Fox 38 29 Float GRIP Performance; shock: RockShox Super Deluxe Select vs Fox Float-X LV Performance; derailleur: Sram 70 Eagle vs Sram S1000 Eagle AXS; price: €6,499 vs €7,499.
