MondrakerZendit RR
- Motor
- DJI Avinox M2S150 Nm; 1300 W peak
- Battery
- 800 WhIntegrated, non-removable
- Travel F / R
- 170 / 165 mm
- Wheels
- Mullet 29" / 27.5"
- Frame
- Stealth Air carbon
- Weight
- 22.8 kgManufacturer figure
Overview
The Zendit RR is the €8,499 entry to the full-carbon frame, with a Fox 38 Factory fork and Float X Factory shock, wireless SRAM S1000 Eagle AXS Transmission, Maven Base brakes and DT Swiss H 1900 wheels. Mondraker claims 22.8 kg.
Zendit is Mondraker's flagship full-power enduro eMTB, built around the DJI Avinox M2S motor (up to 150 Nm and 1,300 W) and an integrated 800 Wh battery. It runs a mullet wheel setup with a 170 mm fork and 165 mm of rear travel from the ZERO suspension system, flip-chip adjustable geometry with a 63.5° head angle and five sizes from S to XL.
The XR, RR S and RR use a full Stealth Air carbon frame that can also be set up with a 29" rear wheel. The R and S, added in October 2026, pair the same carbon front triangle with an alloy swingarm and rocker link and are mullet-only.
- DJI Avinox M2S: up to 150 Nm and 1,300 W
- Integrated 800 Wh battery
- 170 mm fork, 165 mm rear travel, mullet wheels
- Flip-chip geometry, 63.5° head angle
Gallery
Full specifications
Frame & suspension
- Frame
- Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
- Sizes
- S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
- Rear shock
- Fox Float X Factory Kashima Evol LV 205x65mm. 2-positions lever compresion (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.
- Shock settings
- CS 30 compression, 1,1 Bleed, RL50 rebound, Rezi B40, LML, standard MCU, 0 volume spacers
- Fork
- Fox 38 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 15x110mm Kabolt axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload.
E-system
- Display
- Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)
- Motor
- Avinox M2S
- Battery
- Avinox 800Wh Battery / Avinox 4A Charger
Drivetrain
- Crankset
- e*thirteen Helix Core e*spec alloy. All sizes: 155mm Offset 26.5 mm
- Chainring
- Sram Eagle 36T T-Type, 104BCD, steel, CL55
- Chain
- Sram GX Eagle T-Type, 12s Flattop, w/Powerlock
- Rear derailleur
- Sram S1000 Eagle AXS, T-Type, 12s
- Shift levers
- Sram Eagle AXS Pod Controller w/discrete clamp, 12s
Zendit geometry
| Size | S | M | M/L | L | XL |
|---|---|---|---|---|---|
| ASeat tube length | 380 mm | 410 mm | 435 mm | 460 mm | 490 mm |
| BTop tube length | 586 mm | 606 mm | 628 mm | 650 mm | 672 mm |
| CBottom bracket drop | 6 mm | 6 mm | 6 mm | 6 mm | 6 mm |
| DBottom bracket height | 345 mm | 345 mm | 345 mm | 345 mm | 345 mm |
| EChainstay length | 450 mm | 450 mm | 450 mm | 455 mm | 455 mm |
| FSeat tube angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| GEffective seat tube angle | 77° | 77° | 77° | 77° | 77° |
| HHead tube angle | 63.5° | 63.5° | 63.5° | 63.5° | 63.5° |
| IFork Offset | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| JWheelbase | 1241 mm | 1261 mm | 1286 mm | 1315 mm | 1339 mm |
| KHead tube length | 110 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| LReach | 440 mm | 460 mm | 480 mm | 500 mm | 520 mm |
| MStack | 631 mm | 631 mm | 640 mm | 649 mm | 658 mm |
Standard flip-chip position (the low setting slackens the head angle to 63.15° and lowers the bottom bracket by 5 mm). Source: Mondraker.
Zendit: builds compared
Zendit range →| Zendit S | Zendit R | Zendit RR | Zendit RR S | Zendit XR | |
|---|---|---|---|---|---|
| Price | €6,499 | €7,499 | €8,499 | €10,499 | €12,499 |
| Frame | Carbon front, alloy rear | Carbon front, alloy rear | Stealth Air carbon | Stealth Air carbon | Stealth Air carbon |
| Fork | RockShox ZEB Base 29, Delta RC | Fox 38 29 Float GRIP Performance, 170mm | Fox 38 29 Float GRIP X2 Factory Kashima, 170mm | Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm | Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm |
| Shock | RockShox Super Deluxe Select | Fox Float-X LV Performance | Fox Float X Factory Kashima Evol LV 205x65mm | Fox Float X Factory Kashima Evol LV 205x65mm | Fox Float X2 Factory Kashima 205x65mm |
| Derailleur | Sram 70 Eagle | Sram S1000 Eagle AXS | Sram S1000 Eagle AXS | Sram X0 Eagle AXS T-Type | Sram X0 Eagle AXS T-Type |
| Brakes | Sram Maven Base | Sram Maven Base | Sram Maven Base | Sram Maven Silver | Sram Maven Ultimate |
| Wheels | Mavic E-Access XR30, aluminium | DT Swiss Hybrid H 1900 SPLINE, aluminum | DT Swiss Hybrid H 1900 SPLINE, aluminum | DT Swiss Hybrid HX 1700 Spline, 30mm internal width | DT Swiss Hybrid HXC 1500 Spline, Carbon |
| Display | Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R) | Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R) |
Zendit RR: FAQ
How much does the Mondraker Zendit RR cost?
€8,499 (RRP Germany, VAT incl.). The Zendit range runs from €6,499 (Zendit S) to €12,499 (Zendit XR). Prices vary by country and dealer.
How much does the Mondraker Zendit RR weigh?
Mondraker quotes 22.8 kg. It is the lightest build of the Zendit.
What motor and battery does the Mondraker Zendit RR have?
DJI Avinox M2S (150 Nm; 1300 W peak). 800 Wh battery — integrated, non-removable.
How much suspension travel does the Mondraker Zendit RR have?
170 mm at the fork and 165 mm at the rear, on mullet 29" / 27.5" wheels.
What sizes does the Mondraker Zendit RR come in?
S, M, M/L, L, XL. Check the geometry table to compare reach and stack between sizes.
What is the difference between the Zendit RR and the Zendit RR S?
They share the Zendit frame platform and motor; the differences are in the parts — fork: Fox 38 29 Float GRIP X2 Factory Kashima vs Fox Podium 29 Float GRIP X2 Factory Kashima; derailleur: Sram S1000 Eagle AXS vs Sram X0 Eagle AXS T-Type; brakes: Sram Maven Base vs Sram Maven Silver; price: €8,499 vs €10,499.
