CanyonNeuron:ON 8
- Motor
- Bosch Performance Line CX85 Nm; 120 Nm with Bosch Performance Upgrade
- Battery
- 800 Wh
- Travel F / R
- 150 / – mm
- Wheels
- 29" (XS–S: 27.5")
- Frame
- Alloy
- Weight
- 25.6 kgSize M, manufacturer figure
Overview
The Neuron:ON 8 (€4,499) steps up to the Bosch Performance Line CX motor with an 800 Wh battery and a 150 mm RockShox Lyrik fork, keeping Shimano Deore shifting and 4-piston brakes. Claimed weight is 25.6 kg.
The Neuron:ON is Canyon's alloy full-power trail eMTB for long rides: a 150 mm fork, 29-inch wheels (27.5-inch on XS and S) and Bosch power — the PX motor on the Neuron:ON 7, the CX on the 8 and 9 AXS — with up to 800 Wh of battery and a 250 Wh range-extender option.
- Alloy frame, 150 mm fork
- Bosch PX or CX motor
- Up to 800 Wh, range extender option
- Sizes XS–XL with size-specific wheels
Gallery
Photos: Canyon
Full specifications
Frame & suspension
- Frame
- Neuron:ON — Axle dimension: 12x148 mm, Material: Aluminium (AL)
- Rear Shock
- RockShox Deluxe Select — Fitting Length: 210X55
- Fork
- RockShox Lyrik — Axle dimension: 15x110 mm, Stanchion Diameter: 35 mm, Travel: 150 mm, Offset: 44 mm
- Seatpost Clamp
- Canyon GP0446-01
E-system
- Motor
- Bosch Performance Line CX
- Display
- Bosch Purion 200 BRC3800
- Battery Charger
- Bosch 4A
Drivetrain
- Rear Derailleur
- Shimano Deore
- Chainguard
- Canyon GP0480-01 slim
- Shift Lever
- Shimano M6200
- Cassette
- Shimano M6200 — Number of sprockets: 12, Range: 10-51
- Crank
- FSA CK-745/IS/GEN4 — Crank Length: 165,0
- Chainring
- FSA WB493
- Chain
- Shimano Deore M6100
Brakes
- Brake
- Shimano M6120 — Number of pistons: 2
- Brake
- Shimano Deore 4 Piston — Number of pistons: 4
- Brake Rotor
- Shimano SM-RT30 — Disc Size: 203 / 203
Wheels & tyres
- Front Wheel
- XC 30 AL :ON — Axle dimension: 15x110 mm, Rim material: Aluminium
- Rear Wheel
- XC 30 AL :ON — Axle dimension: 12x148 mm, Rim material: Aluminium
- Tyre
- Schwalbe Romy Trail Pro Radial — Width: 2,5"
- Tyre
- Schwalbe Romy Trail Pro Radial — Width: 2,5"
- Thru Axle
- Canyon Quixle — Axle dimension: 12x148 mm
Cockpit
- Stem
- Canyon:ON ST0031
- Grips
- Ergon GE10 Evo
- Saddle
- Ergon SM10 Enduro Neo
- Seatpost
- Canyon SP0081 — Material: Aluminium (AL)
Other
- Pedals
- Flat Pedals
Manufacturer specification — source. Specs and prices can change; check with the brand or your dealer.
Neuron:ON geometry
| Size | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Body Height | ≤ 166 cm | 166 - 175 cm | 175 - 183 cm | 183 - 192 cm | ≥ 192 cm |
| ASeat Height | 618 - 797 mm | 632 - 831 mm | 717 - 901 mm | 737 - 921 mm | 762 - 951 mm |
| BSeat Tube Length | 371 mm | 391 mm | 421 mm | 441 mm | 461 mm |
| CTop Tube Length | 560 mm | 581 mm | 614 mm | 643 mm | 675 mm |
| DHead Tube Length | 151 mm | 163 mm | 133 mm | 143 mm | 155 mm |
| EHead Tube Angle | 64.1° | 64.1° | 64.1° | 64.1° | 64.1° |
| FSeat Tube Angle | 71° | 71° | 71° | 71° | 71° |
| GChainstay Length | 452 mm | 452 mm | 455 mm | 455 mm | 455 mm |
| HWheel Base | 1214 mm | 1235 mm | 1258 mm | 1288 mm | 1318 mm |
| IStack | 626 mm | 637 mm | 647 mm | 656 mm | 666 mm |
| JReach | 414 mm | 429 mm | 455 mm | 480 mm | 505 mm |
| KStand-over Height | 784 mm | 782 mm | 780 mm | 778 mm | 776 mm |
| LBottom Bracket Offset | 10 mm | 10 mm | 30 mm | 30 mm | 30 mm |
Source: Canyon.
Neuron:ON: builds compared
Neuron:ON range →| Neuron:ON 7 | Neuron:ON 8 | Neuron:ON 9 AXS | |
|---|---|---|---|
| Price | €3,999 | €4,499 | €5,499 |
| Frame | Alloy | Alloy | Alloy |
| Fork | RockShox Psylo Silver RC | RockShox Lyrik | FOX 36 Performance |
| Shock | RockShox Deluxe Select | RockShox Deluxe Select | FOX Float Rhythm |
| Derailleur | Shimano Deore | Shimano Deore | SRAM S1000 Eagle AXS Transmission |
| Brakes | Shimano M6120 | Shimano M6120 | SRAM Maven |
| Wheels | XC 30 AL :ON | XC 30 AL :ON | XC 30 AL :ON |
| Display | Bosch Purion 200 BRC3800 | Bosch Purion 200 BRC3800 | Bosch Kiox 300 |
| Weight | 26.5 kg | 25.6 kg | 25.9 kg |
Neuron:ON 8: FAQ
How much does the Canyon Neuron:ON 8 cost?
€4,499 (RRP Germany, VAT incl.). The Neuron:ON range runs from €3,999 (Neuron:ON 7) to €5,499 (Neuron:ON 9 AXS). Prices vary by country and dealer.
How much does the Canyon Neuron:ON 8 weigh?
Canyon quotes 25.6 kg. It is the lightest build of the Neuron:ON.
What motor and battery does the Canyon Neuron:ON 8 have?
Bosch Performance Line CX (85 Nm; 120 Nm with Bosch Performance Upgrade). 800 Wh battery.
How much suspension travel does the Canyon Neuron:ON 8 have?
150 mm at the fork, on 29" (XS–S: 27.5") wheels.
What sizes does the Canyon Neuron:ON 8 come in?
XS, S, M, L, XL. Check the geometry table to compare reach and stack between sizes.
What is the difference between the Neuron:ON 8 and the Neuron:ON 9 AXS?
They share the Neuron:ON frame platform and motor; the differences are in the parts — fork: RockShox Lyrik vs FOX 36 Performance; shock: RockShox Deluxe Select vs FOX Float Rhythm; derailleur: Shimano Deore vs SRAM S1000 Eagle AXS Transmission; claimed weight: 25.6 kg vs 25.9 kg; price: €4,499 vs €5,499.
