MegamoRyal
- Price
- €4,299 – €6,999
- Motor
- DJI Avinox M2110 Nm (125 Nm Boost); 1,100 W peak
- Battery
- 800 WhRemovable (RS800), key lock
- Travel F / R
- 160 / 160 mm
- Wheels
- 29"
Overview
The Ryal is Megamo's aluminium Avinox e-MTB with 160 mm of travel front and rear, 29-inch wheels and a removable 800 Wh battery (RS800) with a key lock. Megamo describes it as sharing the Reason's DNA with a more relaxed geometry: shorter reach, higher stack and longer chainstays.
The 03 AXS and 05 use the DJI Avinox M2S (130 Nm, 150 Nm and 1,500 W in Boost mode), the 08 and 10 the Avinox M2 (110 Nm, 125 Nm and 1,100 W in Boost). All builds use the DPC100 2-inch OLED display, the frame accepts dual-chamber shocks and cables can be routed internally or externally.
- Aluminium frame, 160/160 mm travel
- Removable 800 Wh battery
- Avinox M2S or M2 motor
- More relaxed geometry than the Reason
Megamo Ryal builds
Ryal builds compared
| Ryal 10 | Ryal 08 | Ryal 05 | Ryal 03 AXS | |
|---|---|---|---|---|
| Price | €4,299 | €4,799 | €5,499 | €6,999 |
| Frame | Alloy | Alloy | Alloy | Alloy |
| Fork | Rock Shox Psylo Silver RC, 160 mm Travel | Rock Shox Zeb Base, 160 mm Travel | Fox 38 Float Performance E-Bike Optimized, 160mm Travel | Fox 38 Float Factory E-Bike Optimized, 160mm Travel |
| Shock | Rock Shox Deluxe Select+ | Rock Shox Deluxe Select+ | Fox Float Rhythm | Fox Float X Factory |
| Derailleur | Shimano XT M8100 | Sram 70 EAGLE T-TYPE | Sram 90 EAGLE T-TYPE | Sram S1000 EAGLE AXS T-TYPE |
| Brakes | Shimano MT520 | Sram Maven Base | Shimano XT M8220 | Shimano XT M8220 |
| Display | Avinox DPC100 | Avinox DPC100 | Avinox DPC100 | Avinox DPC100 |
Ryal geometry
| Size | S | M | L | XL |
|---|---|---|---|---|
| ATop tube | 580 mm | 604 mm | 634 mm | 656 mm |
| BChainstay | 455 mm | 455 mm | 455 mm | 455 mm |
| CSeat tube | 390 mm | 410 mm | 430 mm | 460 mm |
| DHead tube | 105 mm | 125 mm | 145 mm | 155 mm |
| EReach | 435 mm | 455 mm | 480 mm | 500 mm |
| FStack | 629 mm | 647 mm | 665 mm | 674 mm |
| GBB drop | 30 mm | 30 mm | 30 mm | 30 mm |
| HHead angle | 64.4° | 64.4° | 64.4° | 64.4° |
| ISeat angle | 77° | 77° | 77° | 77° |
| JWheelbase | 1221 mm | 1249 mm | 1283 mm | 1307 mm |
Source: Megamo.
Megamo Ryal: FAQ
How much does the Megamo Ryal cost?
€4,299 – €6,999 depending on the build (Ryal 10 €4,299, Ryal 08 €4,799, Ryal 05 €5,499, Ryal 03 AXS €6,999); RRP Spain (megamo.com, EN), VAT incl..
How many Megamo Ryal builds are there?
4: Ryal 10, Ryal 08, Ryal 05, Ryal 03 AXS. They share the frame platform and differ mainly in suspension, drivetrain, wheels and weight.
What motor and battery does the Megamo Ryal use?
DJI Avinox M2 (110 Nm (125 Nm Boost); 1,100 W peak) with a 800 Wh battery (removable (rs800), key lock).
How much travel does the Megamo Ryal have?
160 mm fork and 160 mm rear travel on 29" wheels.
