HusqvarnaLight Cross LC1
- Motor
- Shimano EP685 Nm
- Battery
- 504 WhCore S1+, integrated
- Travel F / R
- 120 / 120 mm
- Wheels
- Mullet 29" / 27.5"
- Frame
- Alloy
- Weight
- 24.5 kgManufacturer figure (size not stated)
All Shimano EP810 / EP801 / EP6 eMTBs →
Watching this bike? Get new models and updates on Telegram →
Overview
€2,999 is the cheapest way into the Light Cross: 120 mm travel, Shimano EP6 with a 504 Wh battery, Suntour suspension and Tektro parts. Claimed 24.5 kg.
The Light Cross LC1 is one of 6 builds of the Husqvarna Light Cross. About the Light Cross range and all its builds →
Gallery
Photos: Husqvarna
Full specifications
Frame & suspension
- Frame
- 29/27.5", Alloy 6061, Integrated battery, Boost, New HQV Alloy, 120 mm
- Fork
- SR SUNTOUR XCR34 Boost LOR, remote lockout, Air, 120 mm, tapered
- Rear shock
- SR SUNTOUR Raidon R, Air, 190x45 mm
- Headset
- Acros ICR, blocklock, ZS56/ZS56
E-system
- Motor
- Shimano EP6, DU-EP600, 250 W, 85 Nm
- Battery
- Core S1+, 504 Wh, 36 V
- Charger
- Charger S, 4 A
- Mode Switch
- Shimano SW-EN600-L
- Display
- Shimano SC-EN600, LCD-Display, Bluetooth
Drivetrain
- Rear derailleur
- Tektro RD-M350, 9-S
- Cassette
- Tektro CS-M350, 11-46 T
- Chain
- KMC e9S
- Chainring
- Husqvarna, Narrow Wide, 34 T
- Cranks
- Shimano FC-EM600, Aluminum forged, Shimano EP24
- Shift lever
- Tektro SL-M350R
- Chain guide
- Husqvarna CGU
Brakes
- Front brake
- Tektro Draco, 2-piston, Hydraulic disc brake
- Front brake rotor
- Tektro TR35, 203 mm, Center lock
- Rear brake
- Tektro Draco, 2-piston, Hydraulic disc brake
- Rear brake rotor
- Tektro TR35, 180 mm, Center lock
Wheels & tyres
- Front wheel
- Rim: Ryde Disc30, With eyelets, Tubeless ready / Hub: Husqvarna DA210F, Center lock, 15x110 mm, thru axle
- Rear wheel
- Rim: Ryde Disc30, With eyelets, Tubeless ready / Hub: Husqvarna DA210R, Center lock, 12x148 mm, thru axle
- Front tyre
- Maxxis Rekon, 62-622, 29 x 2.4, Tubeless ready
- Rear tyre
- Maxxis Rekon, 62-584, 27.5 x 2.4, Tubeless ready
Cockpit
- Stem
- Husqvarna 35, 0 °, Ahead
- Handlebar
- Husqvarna Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
- Grips
- Husqvarna MTB, Lock-on grips
- Saddle
- Husqvarna MTB
- Seatpost
- Husqvarna, 31.6 mm, Dropper post
Other
- Pedals
- Husqvarna, aluminum
- Max. system weight
- 130 kg
- Weight
- 24.5 kg (manufacturer figure)
Manufacturer specification (source). Specs and prices can change; check with the brand or your dealer.
Light Cross geometry
| Size | S | M | L | XL |
|---|---|---|---|---|
| ATop tube length | 572 mm | 609 mm | 638 mm | 666 mm |
| BSeat tube length | 410 mm | 435 mm | 460 mm | 485 mm |
| CSeat tube angle | 75.3° | 75.1° | 75° | 74.9° |
| DHead tube length | 130 mm | 130 mm | 145 mm | 155 mm |
| EHead angle | 66.5° | 66.5° | 66.5° | 66.5° |
| FChainstay length | 445 mm | 445 mm | 445 mm | 445 mm |
| GWheelbase | 1158 mm | 1190 mm | 1221 mm | 1250 mm |
| IBB drop | 23 mm | 23 mm | 23 mm | 23 mm |
| JStack | 599 mm | 633 mm | 646 mm | 656 mm |
| KReach | 415 mm | 440 mm | 465 mm | 490 mm |
| LStem length | 50 mm | 50 mm | 50 mm | 50 mm |
| MCrank length | 165 mm | 165 mm | 165 mm | 165 mm |
Source: Husqvarna E-Bicycles.
Light Cross: builds compared
Light Cross range →| Light Cross LC1 | Light Cross LC2 | Light Cross LC3 | Light Cross LC4 | Light Cross LC5 | Light Cross LC6 | |
|---|---|---|---|---|---|---|
| Price | €2,999 | €3,199 | €3,499 | €3,999 | €4,399 | €4,899 |
| Frame | Alloy | Alloy | Alloy | Carbon main frame, alloy rear | Carbon main frame, alloy rear | Carbon main frame, alloy rear |
| Fork | SR SUNTOUR XCR34 Boost LOR, remote lockout | RockShox 35 Silver TK, Solo Air | RockShox 35 Gold RL, DebonAir | SR SUNTOUR Raidon34 Boost LOR, Air | RockShox 35 Gold RL, DebonAir | RockShox Pike Select, DebonAir |
| Shock | SR SUNTOUR Raidon R | SR SUNTOUR Raidon R | RockShox Deluxe Select | SR SUNTOUR Raidon R | RockShox Deluxe Select+ | RockShox SIDLuxe Select+ |
| Derailleur | Tektro RD-M350 | Tektro RD-M350 | SRAM SX Eagle | SRAM SX Eagle | SRAM GX Eagle | SRAM X01 Eagle |
| Brakes | Tektro Draco | Tektro Draco | Shimano BR-MT410 | Shimano BR-MT410 | SRAM G2 R | SRAM G2 R |
| Wheels | Rim: Ryde Disc30 | Rim: Ryde Disc30 | Rim: Ryde Disc30 | Rim: Ryde Disc30 | Rim: Ryde Disc30 | Rim: Ryde Disc30 |
| Display | Shimano SC-EN600 | Shimano SC-EN600 | Shimano SC-EN600 | Shimano SC-EN600 | Shimano SC-EN600 | Shimano SC-EN600 |
| Weight | 24.5 kg | 24.5 kg | 24.4 kg | 24.5 kg | 23.8 kg | 23.2 kg |
Light Cross LC1: FAQ
What is the difference between the Light Cross LC1 and the Light Cross LC2?
They share the Light Cross frame platform and motor; the differences are in the parts: fork: SR SUNTOUR XCR34 Boost LOR vs RockShox 35 Silver TK; price: €2,999 vs €3,199.
