BikeYokeRevive Max 3.0 34.9
€370 RRP from bikeyoke.com (Germany), VAT incl.; €370 (125–160 mm), €400 (185 mm), €420 (213 mm)
- Drop
- 125 / 160 / 185 / 213 mm
- Diameter
- 34.9 mm
- Upper tube
- 28 mm
- Travel adjust
- 5 mm steps
- Weight
- 525–690 g
- Weight
- 585 g34.9 mm, 160 mm drop, claimed
Overview
BikeYoke's Revive Max 3.0 is the 34.9 mm Revive with a 28 mm upper tube for extra stiffness, in 125–213 mm drops. RRP is €370–420.
The Revive Max 3.0 is the 34.9 mm version of BikeYoke's Revive 3.0 hydraulic dropper. BikeYoke says it is a true 34.9 mm design rather than a standard post with a thicker lower tube: the upper tube grows from 25 mm to 28 mm for more stiffness, less flex and smoother sliding.
It shares the Revive 3.0 updates, including lower-stack saddle clamps, a 360° rotatable foot unit, a 3D-forged upper tube, travel adjustment in 5 mm steps and the quick-reset valve. In 34.9 mm it is sold in 125, 160, 185 and 213 mm drops.
- True 34.9 mm design with 28 mm upper tube
- Drops of 125, 160, 185 and 213 mm
- Quick-reset valve and 5 mm travel adjustment
- 525–690 g claimed
Gallery
Full specifications
Chassis
- Drop
- 125 / 160 / 185 / 213 mm (infinitely adjustable)
- Diameter
- 34.9 mm
- Upper tube diameter
- 28 mm
- Overall length (A)
- 381 / 451 / 501 / 566 mm
- Stack height (B)
- 162 / 197 / 222 / 250 mm
- Max. insertion (C)
- 198 / 233 / 258 / 295 mm
- Travel adjustment
- 5 mm increments, 4 × 5 mm spacers included
Damper
- System
- Sealed hydraulic with quick-reset valve
General
- Weight 34.9 mm
- 525 g (125), 585 g (160), 630 g (185), 690 g (213)
- Rider weight limit
- 115 kg incl. equipment
- In the box
- Seatpost, 1600 mm housing, 1800 mm inner wire, cable barrel, 2 housing end caps, cable crimp, air valve adapter, 4x 5 mm travel spacers, Quick-Reset lever
Compatibility
- Remote
- Any cable remote with at least 10 mm cable pull; BikeYoke recommends Triggy Alpha long
- Saddle rails
- Round 7x7 mm and oval 7x9 / 7x10 mm
Manufacturer specification — BikeYoke. Specs and prices can change; check with the brand or your dealer.
BikeYoke Revive versions compared
| Revive 3.0 | Revive Max 3.0 34.9 | |
|---|---|---|
| Price | €350 | €370 |
| Drop | 100 / 125 / 160 / 185 / 213 mm | 125 / 160 / 185 / 213 mm |
| Diameters | 30.9 / 31.6 mm | — |
| Travel adjust | 5 mm steps (4 × 5 mm spacers) | 5 mm steps |
| Stack height | 137–250 mm (B, by drop) | — |
| Weight | 460–650 g | 525–690 g |
| Rider limit | 115 kg | — |
| Diameter | — | 34.9 mm |
| Upper tube | — | 28 mm |
| Weight | 540 g | 585 g |
| E-bike rated | — | — |
eMTBs that come with the BikeYoke Revive
BikeYoke Revive Max 3.0 34.9: FAQ
How much does the BikeYoke Revive Max 3.0 34.9 cost?
€370 (RRP from bikeyoke.com (Germany), VAT incl.; €370 (125–160 mm), €400 (185 mm), €420 (213 mm)). Prices vary by country and retailer.
How much does the BikeYoke Revive Max 3.0 34.9 weigh?
BikeYoke quotes 585 g (34.9 mm, 160 mm drop, claimed).
Is the BikeYoke Revive Max 3.0 34.9 suitable for e-bikes?
BikeYoke does not specifically rate it for e-bikes. Check the manufacturer’s approval and your bike maker’s recommendations before fitting it to an eMTB.
What are the key specs of the BikeYoke Revive Max 3.0 34.9?
Drop: 125 / 160 / 185 / 213 mm; Diameter: 34.9 mm; Upper tube: 28 mm; Travel adjust: 5 mm steps; Weight: 525–690 g.
What other versions of the BikeYoke Revive are there?
Revive 3.0 (€350).
