MeridaETMO
- Motor
- Bosch Performance Line PX90 Nm
- Battery
- 540 WhBosch PowerTube 540, removable
- Travel F / R
- 140 / 142 mm
- Wheels
- Mullet 29" / 27.5"
Overview
The ETMO is Merida's most price-focused Bosch-powered e-MTB, with an aluminium frame derived from the eONE-EIGHTY, mixed 29/27.5-inch wheels and a lifetime frame warranty for Category 4 (all-mountain/enduro) use. The 800 and 700 run 160 mm of travel at both ends; the 500 and 400 builds use a 140 mm fork and a shorter-travel rear end.
Drive units are the Bosch Performance Line CX (120 Nm) on the 800, 700 and PRO builds and the Performance Line PX (90 Nm) on the 500 and 400, with 540, 600 or 800 Wh internal batteries. Merida also offers EQ versions with fenders, lights, kickstand and rear rack.
- Aluminium frame, 160 or ~140 mm travel
- Bosch CX (120 Nm) or PX (90 Nm)
- 540, 600 or 800 Wh internal battery
- Mixed wheels, lifetime frame warranty
Merida ETMO builds
ETMO builds compared
| ETMO 400 | ETMO 400 PRO | ETMO 500 | ETMO 500 PRO | ETMO 700 | ETMO 800 | |
|---|---|---|---|---|---|---|
| Frame | Alloy | Alloy | Alloy | Alloy | Alloy | Alloy |
| Fork | X-Fusion Migo 34 | X-Fusion Migo 34, Air | SR Suntour Zeron 36X, Air | SR Suntour Zeron 36X, Air | RockShox Psylo Silver RC eMTB, Air | Marzocchi Bomber Z eMTB, Air |
| Shock | X-Fusion O2 Pro | X-Fusion O2 Pro | SR Suntour Edge X R | SR Suntour Edge X R | RockShox Deluxe Select | Marzocchi Bomber Air |
| Derailleur | Shimano CUES U4000 | Shimano CUES U4000 | Shimano CUES U6000 | Shimano CUES U6000 | SRAM S100 Eagle Half-Mount | Shimano XT M8230 |
| Brakes | SRAM DB4 stealth | SRAM DB4 stealth | SRAM DB4 stealth | SRAM DB4 stealth | SRAM DB4 stealth | Shimano XT |
| Wheels | MERIDA COMP TR II, 110x15mm width front hub | MERIDA COMP TR II, 110x15mm width front hub | MERIDA COMP TR II, 110x15mm width front hub | MERIDA COMP TR II, 110x15mm width front hub | MERIDA COMP TR II, 110x15mm width front hub | Reynolds 309 Enduro Comp, 30mm inner width |
| Display | Bosch Purion 200 | Bosch Purion 200 | Bosch Purion 200 | Bosch Purion 200 | Bosch Purion 200 | Bosch Purion 400 |
ETMO geometry
| Size | Short | Mid | Long | XLong |
|---|---|---|---|---|
| Wheel size | 29/27.5" | 29/27.5" | 29/27.5" | 29/27.5" |
| STSeat tube | 380 mm | 405 mm | 430 mm | 455 mm |
| TTTop tube | 556 mm | 584 mm | 609 mm | 636 mm |
| CSChainstay | 446 mm | 446 mm | 446 mm | 446 mm |
| HTAHead angle | 65° | 65° | 65° | 65° |
| STASeat angle | 78.5° | 78.5° | 78.5° | 78.5° |
| BDBB drop | 20 mm | 20 mm | 20 mm | 20 mm |
| HTHead tube | 105 mm | 115 mm | 115 mm | 125 mm |
| FLFork length | 580 mm | 580 mm | 580 mm | 580 mm |
| FOFork offset | 44 mm | 44 mm | 44 mm | 44 mm |
| RReach | 425 mm | 450 mm | 475 mm | 500 mm |
| SStack | 644 mm | 653 mm | 653 mm | 662 mm |
| WBWheelbase | 1202 mm | 1231 mm | 1256 mm | 1285 mm |
| SHStandover | 745 mm | 748 mm | 751 mm | 754 mm |
Source: Merida. Values for the stock mixed-wheel (29"/27.5") setup.
Merida ETMO: FAQ
How many Merida ETMO builds are there?
6: ETMO 400, ETMO 400 PRO, ETMO 500, ETMO 500 PRO, ETMO 700, ETMO 800. They share the frame platform and differ mainly in suspension, drivetrain, wheels and weight.
What motor and battery does the Merida ETMO use?
Bosch Performance Line PX (90 Nm) with a 540 Wh battery (bosch powertube 540, removable).
How much travel does the Merida ETMO have?
140 mm fork and 142 mm rear travel on mullet 29" / 27.5" wheels.
