HusqvarnaHard Cross HC3
- Motor
- Shimano EP685 Nm
- Battery
- 630 WhCore S1+, integrated
- Travel F / R
- 180 / 170 mm
- Wheels
- Mullet 29" / 27.5"
- Frame
- Alloy
- Weight
- 24.6 kgManufacturer figure (size not stated)
All Shimano EP810 / EP801 / EP6 eMTBs →
Watching this bike? Get new models and updates on Telegram →
Overview
€4,799 buys a RockShox ZEB Select fork and SRAM GX Eagle on the EP6-powered Hard Cross. At a claimed 24.6 kg it's the lightest Hard Cross, level with the HC5.
The Hard Cross HC3 is one of 5 builds of the Husqvarna Hard Cross. About the Hard Cross range and all its builds →
Gallery
Photos: Husqvarna
Full specifications
Frame & suspension
- Frame
- 29/27.5", Alloy 6061, Integrated battery, Boost, New HQV Alloy, 170 mm
- Fork
- RockShox ZEB Select, DebonAir, Air, 180 mm, tapered
- Rear shock
- RockShox Super Deluxe Select+, Air, 230x65 mm
- Headset
- Acros ICR, blocklock, ZS56/ZS56
E-system
- Motor
- Shimano EP6, DU-EP600, 250 W, 85 Nm
- Battery
- Core S1+, 630 Wh, 36 V, 17.5 Ah
- Charger
- Charger S, 4 A
- Mode Switch
- Shimano SW-EN600-L
- Display
- Shimano SC-EN600, LCD-Display, Bluetooth
Drivetrain
- Rear derailleur
- SRAM GX Eagle, 12-S
- Cassette
- SRAM PG-1230, 11-50 T
- Chain
- SRAM GX Eagle
- Chainring
- SRAM X-Sync Eagle, 34 T
- Cranks
- Shimano FC-EM600, Aluminum forged, Shimano EP24
- Shift lever
- SRAM GX Eagle, Single Click
- Chain guide
- Husqvarna CGU
Brakes
- Front brake
- SRAM G2 R, 4-piston, Hydraulic disc brake
- Front brake rotor
- SRAM Centerline, 200 mm, 6-hole
- Rear brake
- SRAM G2 R, 4-piston, Hydraulic disc brake
- Rear brake rotor
- SRAM Centerline, 200 mm, 6-hole
Wheels & tyres
- Front tyre
- Schwalbe Magic Mary, Evolution, 62-622, 29 x 2.4, Tubeless ready
- Rear tyre
- Schwalbe Hans Dampf, Evolution, 65-584, 27.5 x 2.6, Tubeless ready
Cockpit
- Stem
- Husqvarna 35, 0 °, Ahead
- Handlebar
- Husqvarna Riser 35 mm, 780 mm, Sweep: 9 °, Rise: 20 mm
- Grips
- Husqvarna MTB, Lock-on grips
- Saddle
- Husqvarna MTB
- Seatpost
- Husqvarna Pro, 31.6 mm, Dropper post
Other
- Wheelset
- NEWMEN Evolution E.G, Tubeless ready, 6-hole, 15x110/12x148 mm, thru axle
- Pedals
- Husqvarna, aluminum
- Max. system weight
- 130 kg
- Weight
- 24.6 kg (manufacturer figure)
Manufacturer specification (source). Specs and prices can change; check with the brand or your dealer.
Hard Cross geometry
| Size | S | M | L | XL |
|---|---|---|---|---|
| ATop tube length | 574 mm | 604 mm | 632 mm | 661 mm |
| BSeat tube length | 410 mm | 435 mm | 460 mm | 485 mm |
| CSeat tube angle | 77.4° | 77.3° | 77.2° | 77.2° |
| DHead tube length | 100 mm | 115 mm | 130 mm | 145 mm |
| EHead angle | 64.5° | 64.5° | 64.5° | 64.5° |
| FChainstay length | 445 mm | 445 mm | 445 mm | 445 mm |
| GWheelbase | 1215 mm | 1248 mm | 1277 mm | 1309 mm |
| IBB drop | 18 mm | 18 mm | 18 mm | 18 mm |
| JStack | 647 mm | 661 mm | 674 mm | 687 mm |
| KReach | 430 mm | 455 mm | 480 mm | 505 mm |
| LStem length | 50 mm | 50 mm | 50 mm | 50 mm |
| MCrank length | 160 mm | 160 mm | 160 mm | 160 mm |
Source: Husqvarna E-Bicycles.
Hard Cross: builds compared
Hard Cross range →| Hard Cross HC1 | Hard Cross HC2 | Hard Cross HC3 | Hard Cross HC4 | Hard Cross HC5 | |
|---|---|---|---|---|---|
| Price | €3,799 | €4,299 | €4,799 | €5,199 | €5,999 |
| Frame | Alloy | Alloy | Alloy | Alloy | Alloy |
| Fork | SR SUNTOUR Durolux38 Boost, Air | RockShox Domain R, DebonAir | RockShox ZEB Select, DebonAir | FOX Float 38 Performance, Grip | FOX Float 38 Factory, Grip 2 |
| Shock | SR SUNTOUR TRIAir | RockShox Super Deluxe Select+ | RockShox Super Deluxe Select+ | FOX Float X Performance | FOX Float X2 Factory |
| Derailleur | Tektro RD-M350 | SRAM SX Eagle | SRAM GX Eagle | SRAM GX Eagle | SRAM X01 Eagle |
| Brakes | SRAM DB8 | SRAM DB8 | SRAM G2 R | SRAM G2 RSC | Magura MT7 |
| Wheels | Rim: Ryde Disc30 | Rim: Ryde Disc30 | — | — | — |
| Display | Shimano SC-EN600 | Shimano SC-EN600 | Shimano SC-EN600 | Shimano SC-EN600 | Shimano SC-EN600 |
| Weight | 25.4 kg | 25.1 kg | 24.6 kg | 25 kg | 24.6 kg |
Hard Cross HC3: FAQ
What is the difference between the Hard Cross HC3 and the Hard Cross HC4?
They share the Hard Cross frame platform; the differences are in the parts: fork: RockShox ZEB Select vs FOX Float 38 Performance; shock: RockShox Super Deluxe Select+ vs FOX Float X Performance; brakes: SRAM G2 R vs SRAM G2 RSC; claimed weight: 24.6 kg vs 25 kg; price: €4,799 vs €5,199.
