EXT Vaia, product shot
Photo: EXT
ForkE-bike rated
EXT Vaia range

EXTVaia

€2,600 EU RRP (listed as €/$)

Travel
170-200 mm
Stanchions
38.5 mm, upside-down
Spring
HS3 air, 2 positive chambers
Damper
3-way: LSC, HSC, rebound
Offset
44 / 48 mm
E-bike
Adaptable to e-MTB use
Weight
3,195 g200 mm travel, 20 mm axle, cut steerer, oil included, claimed

Overview

EXT Vaia: upside-down dual-crown fork with 38.5 mm stanchions and 170-200 mm travel for DH, enduro and e-MTB, 3195 g, priced at EUR 2,600.

Vaia is EXT's upside-down, dual-crown gravity fork with tapered 38.5 mm stanchions, which EXT calls the only upside-down dual-crown DH fork on the market. Designed for downhill but adaptable to aggressive enduro and e-MTB use, it offers 170 to 200 mm of travel and interchangeable 15 mm (110 Boost) and 20 mm Grade 5 titanium axles.

A cam stem developed with Mojo Rising gives two offsets (44 and 48 mm) from one stem and crown, and two top-crown drops suit different head-tube lengths. Inside are EXT's HS3 air cartridge with two positive chambers and a volume-tunable negative chamber, floating DU bushings with a long overlap, and a high-flow 3-way cartridge with independent high/low-speed compression and rebound.

  • Upside-down dual-crown fork, 170-200 mm travel
  • Tapered 38.5 mm stanchions; 7075/7050 alloy and Grade 5 titanium
  • Two offsets (44/48 mm) with one stem and crown
  • Interchangeable 15 mm Boost and 20 mm titanium axles
  • HS3 air spring with tunable chamber volumes; 3-way damper

Gallery

Full specifications

Chassis

Construction
Dual-crown upside-down; 7075 and 7050 T6 alloy and Grade 5 titanium
Stanchions
Tapered 38.5 mm, proprietary surface finish
Travel
170, 180, 190, 200 mm
Axle to crown
170 mm: 574-584 mm; 180 mm: 584-594 mm; 190 mm: 594-604 mm; 200 mm: 604-614 mm
Offset
44 or 48 mm (cam stem, one stem and crown)
Top crown drop
10 mm (head tube 107-136 mm) or 30 mm (head tube 127-156 mm)
Bushings
Floating DU bushing system (CGB), 240 mm overlap around sag at 200 mm travel
Axle
Interchangeable Grade 5 titanium 20 mm and 15 mm (110 Boost)
Rotor size
200 mm, up to 220 mm with adapter

Spring

Spring type
HS3 air cartridge: 2 independent positive chambers + negative chamber with tunable volume (volume spacers)
Bleed
Pressure release bleed buttons on both legs

Damper

Cartridge
High-flow, 3-way adjustable
Adjustments
Independent high/low-speed compression and rebound

General

Hardware
Grade 5 titanium washers and hardware
Fender
Dedicated stanchion protection with available bolt-on fender
Warranty
5 years (from 21 November 2024)

Manufacturer specification from EXT. Specs and prices can change; check with the brand or your dealer.

EXT Vaia: FAQ

How much does the EXT Vaia cost?

€2,600 (EU RRP (listed as €/$)). Prices vary by country and retailer.

How much does the EXT Vaia weigh?

EXT quotes 3,195 g (200 mm travel, 20 mm axle, cut steerer, oil included, claimed).

Is the EXT Vaia suitable for e-bikes?

Yes. EXT lists it as e-bike rated or e-bike specific.

What are the key specs of the EXT Vaia?

Travel: 170-200 mm; Stanchions: 38.5 mm, upside-down; Spring: HS3 air, 2 positive chambers; Damper: 3-way: LSC, HSC, rebound; Offset: 44 / 48 mm; E-bike: Adaptable to e-MTB use.
