OneUpV2 Carbon Handlebar
€169.99 RRP from OneUp EU store (eu.oneupcomponents.com), VAT incl.; on sale from €119.99 at time of capture
- Width
- 760 / 800 mm
- Rise
- 20 / 35 / 50 mm
- Clamp
- 35 mm
- Sweep
- 8° back / 5° up
- Weight
- 220–265 g
- Weight
- 235 g800 mm, 35 mm rise, claimed
Overview
OneUp's V2 Carbon Handlebar comes in 760/800 mm widths and 20–50 mm rises with a 35 mm clamp, weighing 220–265 g. EU RRP is €169.99.
The V2 Carbon Handlebar is OneUp's compliance-focused 35 mm-clamp carbon bar for trail and enduro riding. It is offered in 760 and 800 mm widths with 20 or 35 mm rise, plus a 50 mm rise in the 800 mm width, all with 8° backsweep and 5° upsweep.
Claimed weights run from 220 g to 265 g depending on size. The bar is sold without decals; OneUp offers decal kits in a wide range of colours.
- 760 or 800 mm widths; 20, 35 and 50 mm rise options
- 35 mm clamp, 8° backsweep, 5° upsweep
- Claimed 220–265 g
- Max stem clamp width 60 mm
- Decal kits sold separately
Gallery
Full specifications
General
- Width
- 800mm (minimum width 740mm), 760mm (minimum width 720mm)
- Rise Options
- 20mm, 35mm, (760mm and 800mm widths) and 50mm (800mm width)
- Backsweep
- 8°
- Upsweep
- 5°
- Diameter
- 35mm
- Weights
- 760x20: 220g 760x35: 220g 800x20: 235g 800x35: 235g 800x50: 265g
- Max Stem Clamp Width
- 60mm (800mm & 760mm width)
- Max Stem Clamp Torque
- 6Nm
- Max Lever Clamp Torque
- 5Nm
- Handlebar Colour
- Carbon (Black)
- Decal Kit Colours
- Red, Green, Blue, Orange, Purple, White, Gloss Black, Turquoise, Oil Slick, Silver, Gold Matte Metallic, Bronze Matte Metalic
Manufacturer specification — OneUp. Specs and prices can change; check with the brand or your dealer.
OneUp Carbon Handlebar versions compared
| Carbon E-Bar | V2 Carbon Handlebar | |
|---|---|---|
| Price | €169.99 | €169.99 |
| Width | 800 mm (min. trim 740 mm) | 760 / 800 mm |
| Rise | 35 mm | 20 / 35 / 50 mm |
| Clamp | 35 mm | 35 mm |
| Sweep | 8° back / 5° up | 8° back / 5° up |
| E-bike | Integrated ports for e-bike controls | — |
| Weight | — | 220–265 g |
| Weight | 238 g | 235 g |
OneUp V2 Carbon Handlebar: FAQ
How much does the OneUp V2 Carbon Handlebar cost?
€169.99 (RRP from OneUp EU store (eu.oneupcomponents.com), VAT incl.; on sale from €119.99 at time of capture). Prices vary by country and retailer.
How much does the OneUp V2 Carbon Handlebar weigh?
OneUp quotes 235 g (800 mm, 35 mm rise, claimed).
Is the OneUp V2 Carbon Handlebar suitable for e-bikes?
OneUp does not specifically rate it for e-bikes. Check the manufacturer’s approval and your bike maker’s recommendations before fitting it to an eMTB.
What are the key specs of the OneUp V2 Carbon Handlebar?
Width: 760 / 800 mm; Rise: 20 / 35 / 50 mm; Clamp: 35 mm; Sweep: 8° back / 5° up; Weight: 220–265 g.
What other versions of the OneUp Carbon Handlebar are there?
Carbon E-Bar (€169.99).
