SpecializedTurbo Levo 4 EVO Comp
- Motor
- Specialized 3.1105 Nm, 810 W
- Battery
- 840 WhSide-entry, integrated
- Travel F / R
- 180 / 170 mm
- Wheels
- Mullet 29" / 27.5"
- Frame
- FACT 11m carbon
- Weight
- 25.2 kgSize S4, manufacturer figure
Overview
The Turbo Levo 4 EVO Comp ($8,199.99) is the entry long-travel Levo: a FACT 11m carbon frame with 170 mm rear travel, a 180 mm RockShox ZEB Select fork and Vivid Select air shock, SRAM S1000 AXS and Maven Bronze brakes, at a claimed 25.16 kg (S4).
The Turbo Levo 4 EVO is the long-travel version of the Levo 4: a FACT 11m carbon frame with 170 mm of rear travel, a 180 mm RockShox ZEB fork and a Vivid air shock, with a 29-inch front wheel and a 27.5-inch downhill tyre at the rear.
Power comes from the same Specialized 3.1 motor (105 Nm, 810 W) and 840 Wh battery as the standard Levo 4.
- 170 mm rear / 180 mm fork travel
- Specialized 3.1 motor, 105 Nm, 810 W
- 840 Wh battery
- FACT 11m carbon frame, UDH compatible
Gallery
Photos: Specialized
Full specifications
Frame & suspension
- Frame
- Levo Evo FACT 11m carbon frame, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm rear travel, 29" front wheel/27.5" rear wheel, adjustable head tube angle, chainstay length, integrated SWAT storage
- Seat Binder
- Alloy, 38.6mm
- Rear Shock
- All New Vivid Select air, 230x62.5mm, Linear XL spring, RT damper w/climb switch, rebound adjust
- Fork
- All New SRAM FS ZEB Select, 29" 180mm, Linear XL spring, Delta RC damper, rebound adjust
E-system
- Motor
- Specialized 3.1 Motor, 105Nm torque, 810W power
- Battery
- 840Wh battery
- UI/Remote
- Mastermind TCU, 2.2" high resolution screen, fully customizeable with Specialized app, works with Apple Find My
- Charger
- Specialized 4amp charger
Drivetrain
- Shift Levers
- SRAM AXS Pod Controller w/discrete clamp
- Rear Derailleur
- SRAM S1000 Eagle AXS
- Cassette
- SRAM 12-speed,10-52t
- Chain
- SRAM GX Eagle Transmission 12-Speed Flattop Chain
- Crankset
- SRAM S1000 Alloy crank, ISIS interface, 155mm length
- Chainrings
- SRAM 34t T-Type chainring, 104 BCD, steel
Brakes
- Front Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor
- Rear Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm rotor
Wheels & tyres
- Rims
- Specialized Alloy Rims
- Front Hub
- Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 28h
- Rear Hub
- Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 32h, HG Steel Fhb
- Spokes
- DT Swiss Elemental
- Front Tyre
- Butcher, GRID Gravity, T9, TLR, 29x2.4"
- Rear Tyre
- Cannibal GRID Gravity T9 TLR Downhill Tire 27.5x2.4"
- Inner Tubes
- Standard, Presta Valve
Cockpit
- Stem
- Alloy Trail Stem, 35mm bar bore
- Handlebars
- Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise
- Grips
- Specialized Trail Grips
- Saddle
- Bridge Comp, Hollow Cr-mo rails 155/143
- Seatpost
- Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 200mm
Other
- SWAT
- SWAT Internal downtube storage
Manufacturer specification — source. Specs and prices can change; check with the brand or your dealer.
Turbo Levo 4 EVO geometry
| Size | S2 | S3 | S4 | S5 | S6 |
|---|---|---|---|---|---|
| Crank Length | 155 mm | 155 mm | 155 mm | 155 mm | 155 mm |
| Handlebar Width | 780 mm | 800 mm | 800 mm | 800 mm | 800 mm |
| Stem Length | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Saddle Width | 155 mm | 143 mm | 143 mm | 143 mm | 143 mm |
| Seatpost Length | 125 mm | 170 mm | 200 mm | 200 mm | 200 mm |
| Stack | 625 mm | 633 mm | 646 mm | 659 mm | 675 mm |
| Reach | 425 mm | 445 mm | 470 mm | 495 mm | 525 mm |
| Head tube Length | 95 mm | 103 mm | 117 mm | 132 mm | 149 mm |
| Head tube Angle | 63.6° | 63.6° | 63.6° | 63.6° | 63.6° |
| BB Height | 356 mm | 356 mm | 356 mm | 356 mm | 356 mm |
| BB Drop | 24 mm | 24 mm | 24 mm | 24 mm | 24 mm |
| Trail | 139 mm | 139 mm | 139 mm | 139 mm | 139 mm |
| Fork Length (full) | 597 mm | 597 mm | 597 mm | 597 mm | 597 mm |
| Fork Rake/Offset | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Front Center | 773 mm | 797 mm | 828 mm | 859 mm | 897 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1208 mm | 1232 mm | 1263 mm | 1294 mm | 1331 mm |
| Top-tube Length (horizontal) | 580 mm | 602 mm | 630 mm | 658 mm | 691 mm |
| Bike Standover Height | 764 mm | 765 mm | 763 mm | 768 mm | 771 mm |
| Seat Tube Length | 390 mm | 405 mm | 425 mm | 445 mm | 465 mm |
| Seat Tube Angle | 76° | 76° | 76° | 76° | 76° |
| Saddle Height for Effective ST Angle | 690 mm | 735 mm | 780 mm | 825 mm | 870 mm |
| Max Seatpost Insertion | 274 mm | 289 mm | 313 mm | 337 mm | 357 mm |
| Min Seatpost Insertion | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
Source: Specialized.
Turbo Levo 4 EVO: builds compared
Turbo Levo 4 EVO range →| Turbo Levo 4 EVO Comp | Turbo Levo 4 EVO Pro | |
|---|---|---|
| Price | $8,199.99 | $10,499.99 |
| Frame | FACT 11m carbon | FACT 11m carbon |
| Fork | All New SRAM FS ZEB Select, 29" 180mm | All New SRAM FS ZEB Ultimate, 29" 180mm |
| Shock | All New Vivid Select air | All New Vivid Ultimate air |
| Derailleur | SRAM S1000 Eagle AXS | SRAM X0 Eagle Transmission |
| Brakes | SRAM Maven Bronze | SRAM Maven Silver |
| Wheels | Specialized Alloy Rims | Traverse HD Carbon 29" rim |
| Weight | 25.2 kg | 24.4 kg |
Turbo Levo 4 EVO Comp: FAQ
How much does the Specialized Turbo Levo 4 EVO Comp cost?
$8,199.99 (US MSRP). The Turbo Levo 4 EVO range runs from $8,199.99 (Turbo Levo 4 EVO Comp) to $10,499.99 (Turbo Levo 4 EVO Pro). Prices vary by country and dealer.
How much does the Specialized Turbo Levo 4 EVO Comp weigh?
Specialized quotes 25.2 kg. The lightest Turbo Levo 4 EVO build is the Turbo Levo 4 EVO Pro at 24.4 kg.
What motor and battery does the Specialized Turbo Levo 4 EVO Comp have?
Specialized 3.1 (105 Nm, 810 W). 840 Wh battery — side-entry, integrated.
How much suspension travel does the Specialized Turbo Levo 4 EVO Comp have?
180 mm at the fork and 170 mm at the rear, on mullet 29" / 27.5" wheels.
What sizes does the Specialized Turbo Levo 4 EVO Comp come in?
S2, S3, S4, S5, S6. Check the geometry table to compare reach and stack between sizes.
What is the difference between the Turbo Levo 4 EVO Comp and the Turbo Levo 4 EVO Pro?
They share the Turbo Levo 4 EVO frame platform and motor; the differences are in the parts — fork: All New SRAM FS ZEB Select vs All New SRAM FS ZEB Ultimate; shock: All New Vivid Select air vs All New Vivid Ultimate air; derailleur: SRAM S1000 Eagle AXS vs SRAM X0 Eagle Transmission; brakes: SRAM Maven Bronze vs SRAM Maven Silver; claimed weight: 25.2 kg vs 24.4 kg; price: $8,199.99 vs $10,499.99.
