PoleHiisi 173 Core
- Motor
- Maxon Air S90 Nm; 620 W peak
- Battery
- 600 WhInternal; 250 Wh range extender available
- Travel F / R
- 180 / 173 mm
- Wheels
- 29"
- Frame
- Alloy
Overview
The Pole Hiisi 173 Core (€14,498) is the entry build of the Hiisi: Maxon Air S (90 Nm) with 600 Wh, RockShox ZEB Ultimate fork, RockShox Vivid Ultimate shock, SRAM GX Eagle AXS T-Type and SRAM Maven Ultimate brakes.
The Hiisi is Pole's full-power e-MTB: every frame part is CNC-machined from solid 7075-T6 aluminium and structurally bonded without welds (±0.05 mm), and each bike is built to order in Jyväskylä, Finland. It uses the Maxon Air S motor (90 Nm, 620 W peak, 2.0 kg) with a 600 Wh internal battery; a 250 Wh range extender is available.
The Hiisi 173 complete builds run 173 mm of rear travel with a 180 mm fork on 29-inch wheels, in frame sizes K1, K2 and K3; geometry is set within each size from the rider's measurements. The wider Hiisi platform covers 152 to 200 mm of rear travel, and Pole quotes about two months from order to shipping.
- Maxon Air S: 90 Nm, 620 W peak, 2.0 kg
- 600 Wh battery, 250 Wh extender optional
- 173 mm rear / 180 mm fork, 29-inch
- CNC-machined, bonded 7075-T6 frame, made in Finland
Gallery
Photos: Pole
Full specifications
Frame & suspension
- Frame
- Pole Hiisi, CNC-machined and bonded 7075-T6 aluminium, 173 mm travel
- Fork
- RockShox ZEB Ultimate, 180 mm
- Rear shock
- RockShox Vivid Ultimate, tuned to rider weight
E-system
- Motor
- Maxon Air S, 90 Nm, 620 W peak, 2.0 kg
- Battery
- 600 Wh internal (250 Wh range extender available)
- Display
- Display and remote included
Drivetrain
- Groupset
- SRAM GX Eagle Transmission
- Rear derailleur
- SRAM GX Eagle AXS T-Type
- Cassette
- SRAM XS-1275
- Chain
- SRAM T-Type
- Shifter
- SRAM AXS Rocker
- Crankset
- e*thirteen Helix Race Alloy e-MTB
Brakes
- Brakes
- SRAM Maven Ultimate
Wheels & tyres
- Wheelset
- Newmen Beskar 30 J-Bend Enduro, 29"
- Tyres
- Schwalbe Magic Mary (front), Tacky Chan (rear), Gravity Pro
Cockpit
- Handlebar
- BikeYoke Barmate AlS 800 x 65 mm
- Stem
- BikeYoke Barkeeper 45 mm
- Grips
- All Mountain Style AMS Cero
- Seatpost
- RockShox Reverb AXS
- Saddle
- BikeYoke SAGMA 3D Lite 142
- Headset
- Enduro ZS44/ZS56
Other
- Colours
- Raw Silver, Hero Bronze, True Gold (Hero Bronze / True Gold +€1,230)
- Warranty
- 5-year frame warranty
Manufacturer specification — source. Specs and prices can change; check with the brand or your dealer.
Hiisi geometry
| Size | K1 | K2 | K3 |
|---|---|---|---|
| Rider height | 157–170 cm | 171–182 cm | 183–198 cm |
| Head angle | 64° | 64° | 64° |
| Reach | 444.7 mm | 474.7 mm | 504.7 mm |
| Stack | 630.99 mm | 630.99 mm | 630.99 mm |
| Front center | 790.83 mm | 820.83 mm | 850.83 mm |
| Chainstay | 451.1 mm | 451.1 mm | 451.1 mm |
| Wheelbase | 1241.93 mm | 1271.93 mm | 1301.93 mm |
| Top tube | 549.5 mm | 579.5 mm | 609.5 mm |
| Head tube | 110 mm | 110 mm | 110 mm |
| Seat tube | 343 mm | 343 mm | 350 mm |
| Seat angle | 80° | 80° | 80° |
| BB drop | -15.56 mm | -15.56 mm | -15.56 mm |
| BB height | 356.6 mm | 356.6 mm | 356.6 mm |
| Fork offset | 44–51 mm | 44–51 mm | 44–51 mm |
| Fork A2C | 596 mm | 596 mm | 596 mm |
Source: Pole (Hiisi 173, full 29-inch configuration). Measured at sag (35% travel); geometry is fine-tuned per rider within each size.
Hiisi: builds compared
Hiisi range →| Hiisi 173 Core | Hiisi 173 Big Build | |
|---|---|---|
| Price | €14,498 | €17,221 |
| Frame | Alloy | Alloy |
| Fork | RockShox ZEB Ultimate, 180 mm | Intend Flash, 180 mm |
| Shock | RockShox Vivid Ultimate | EXT Arma V4 |
| Derailleur | SRAM GX Eagle AXS T-Type | SRAM X0 Eagle AXS T-Type |
| Brakes | SRAM Maven Ultimate | SRAM Maven Ultimate |
| Display | Display and remote included | Display and remote included |
Hiisi 173 Core: FAQ
How much does the Pole Hiisi 173 Core cost?
€14,498 (RRP Finland, VAT incl. (25.5%); Raw Silver finish). The Hiisi range runs from €14,498 (Hiisi 173 Core) to €17,221 (Hiisi 173 Big Build). Prices vary by country and dealer.
What motor and battery does the Pole Hiisi 173 Core have?
Maxon Air S (90 Nm; 620 W peak). 600 Wh battery — internal; 250 Wh range extender available.
How much suspension travel does the Pole Hiisi 173 Core have?
180 mm at the fork and 173 mm at the rear, on 29" wheels.
What sizes does the Pole Hiisi 173 Core come in?
K1, K2, K3. Check the geometry table to compare reach and stack between sizes.
What is the difference between the Hiisi 173 Core and the Hiisi 173 Big Build?
They share the Hiisi frame platform and motor; the differences are in the parts — fork: RockShox ZEB Ultimate vs Intend Flash; shock: RockShox Vivid Ultimate vs EXT Arma V4; derailleur: SRAM GX Eagle AXS T-Type vs SRAM X0 Eagle AXS T-Type; price: €14,498 vs €17,221.
