CanyonSpectral:ONfly CF 9
- Motor
- TQ HPR50
- Battery
- 360 WhTQ battery
- Travel F / R
- 160 / 150 mm
- Wheels
- Mullet 29" / 27.5"
- Frame
- Carbon
- Weight
- 18.8 kgSize M, manufacturer figure
Overview
The Spectral:ONfly CF 9 (RRP €6,299) upgrades to Fox 36 Performance and Float DPS suspension, a Shimano XT derailleur and XT 4-piston brakes; claimed weight is 18.8 kg.
The Spectral:ONfly is the lightweight version of Canyon's trail eMTB: a carbon frame with 150 mm of rear travel and a 160 mm fork, mixed wheels and the compact TQ HPR50 motor with a 360 Wh battery. Claimed weights are under 19 kg.
- TQ HPR50 motor, 360 Wh battery
- 150 mm rear / 160 mm fork
- Carbon frame, mullet wheels
- 18.8–18.9 kg claimed
Gallery
Photos: Canyon
Full specifications
Frame & suspension
- Frame
- Canyon Spectral:ONfly CF — Axle dimension: 12x148 mm, Material: Carbon (CF)
- Rear Shock
- Fox DPS Performance — Fitting Length: 210X55, Rear Suspension Travel: 150
- Fork
- FOX 36 Performance Series — Axle dimension: 15x110 mm, Stanchion Diameter: 36 mm, Travel: 160 mm
- Seatpost Clamp
- Canyon GP0446-01
E-system
- Motor
- TQ HPR 50 Motor
- Battery
- TQ HPR Battery — Battery capacity: 360 Wh
Drivetrain
- Rear Derailleur
- Shimano Deore XT M8100 — Cage length: long
- Chainguard
- Canyon GP0480-01 slim
- Shift Lever
- Shimano Deore SLX M7100
- Cassette
- Shimano Deore M6100 — Number of sprockets: 12, Range: 10-51
- Crank
- FSA CK-745/IS Armset — Crank Length: 170,0
- Chainring
- Chainring FSA W0190
- Chain
- Shimano M6100 12-speed
Brakes
- Brake
- Shimano DEORE XT M8120 — Number of pistons: 4
- Brake
- Shimano DEORE XT M8120 — Number of pistons: 4
- Brake Rotor
- Shimano DEORE XT MT800 — Disc Size: 203 / 203
Wheels & tyres
- Front Wheel
- DT Swiss H1900 29 — Axle dimension: 15x110 mm, Rim material: Aluminium
- Rear Wheel
- DT Swiss HX 1900 Spline LS — Axle dimension: 12x148 mm, Rim material: Aluminium
- Tyre
- MAXXIS Minion DHR II — Width: 2,4"
- Tyre
- Maxxis Minion DHR II Exo — Width: 2.4"
- Thru Axle
- Canyon Quixle — Axle dimension: 12x148 mm
Cockpit
- Stem
- Canyon:ON ST0031 — Rise: 30 mm
- Grips
- Canyon Lock-On
- Saddle
- Fizik Terra Aidon X5
- Seatpost
- Canyon SP0070-01 — Material: Aluminium (AL)
Other
- Pedals
- Flat Pedals
Manufacturer specification — source. Specs and prices can change; check with the brand or your dealer.
Spectral:ONfly geometry
| Size | S | M | L | XL |
|---|---|---|---|---|
| Body Height | ≤ 175 cm | 175 - 183 cm | 183 - 192 cm | ≥ 192 cm |
| ASeat Height | 660 - 785 mm | 705 - 830 mm | 735 - 860 mm | 775 - 900 mm |
| BSeat Tube Length | 400 mm | 415 mm | 445 mm | 455 mm |
| CTop Tube Length | 594 mm | 621 mm | 648 mm | 675 mm |
| DHead Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| EHead Tube Angle | 64° | 64° | 64° | 64° |
| FSeat Tube Angle | 76.5° | 76.5° | 76.5° | 76.5° |
| GChainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| HWheel Base | 1221 mm | 1251 mm | 1280 mm | 1309 mm |
| IStack | 620 mm | 629 mm | 638 mm | 647 mm |
| JReach | 445 mm | 470 mm | 495 mm | 520 mm |
| KStand-over Height | 734 mm | 739 mm | 743 mm | 747 mm |
| LBottom Bracket Offset | 31 mm | 31 mm | 31 mm | 31 mm |
Source: Canyon.
Spectral:ONfly: builds compared
Spectral:ONfly range →| Spectral:ONfly CF 8 | Spectral:ONfly CF 9 | |
|---|---|---|
| Price | €5,599 | €6,299 |
| Frame | Carbon | Carbon |
| Fork | RockShox Lyrik | FOX 36 Performance Series |
| Shock | Rockshox Deluxe Select + | Fox DPS Performance |
| Derailleur | Shimano Deore M6100 | Shimano Deore XT M8100 |
| Brakes | SRAM Code R | Shimano DEORE XT M8120 |
| Wheels | Sunringle 329 Trail Expert | DT Swiss H1900 29 |
| Weight | 18.9 kg | 18.8 kg |
Spectral:ONfly CF 9: FAQ
How much does the Canyon Spectral:ONfly CF 9 cost?
€6,299 (RRP Germany, VAT incl.). The Spectral:ONfly range runs from €5,599 (Spectral:ONfly CF 8) to €6,299 (Spectral:ONfly CF 9). Prices vary by country and dealer.
How much does the Canyon Spectral:ONfly CF 9 weigh?
Canyon quotes 18.8 kg. It is the lightest build of the Spectral:ONfly.
What motor and battery does the Canyon Spectral:ONfly CF 9 have?
TQ HPR50. 360 Wh battery — tQ battery.
How much suspension travel does the Canyon Spectral:ONfly CF 9 have?
160 mm at the fork and 150 mm at the rear, on mullet 29" / 27.5" wheels.
What sizes does the Canyon Spectral:ONfly CF 9 come in?
S, M, L, XL. Check the geometry table to compare reach and stack between sizes.
What is the difference between the Spectral:ONfly CF 9 and the Spectral:ONfly CF 8?
They share the Spectral:ONfly frame platform and motor; the differences are in the parts — fork: FOX 36 Performance Series vs RockShox Lyrik; shock: Fox DPS Performance vs Rockshox Deluxe Select +; derailleur: Shimano Deore XT M8100 vs Shimano Deore M6100; claimed weight: 18.8 kg vs 18.9 kg; price: €6,299 vs €5,599.
